Tag Specification
| Minimum Weight | 2.6g |
| Minimum Dimensions | 40 x 11 x 6mm, plus whip antenna |
| Memory capacity | ~60,000 Location attempts |
| Battery only capacity | ~144 location attempts for 2.6g tag, significantly more with larger battery options |
| Solar capacity | ~40 per day in UK summertime conditions for 2.6g tag, more with larger solar options |
| Programming interface | Wireless programming via base station |
| Waterproofing | All immersion proof, depth proofing also available |
| Packaging type | Epoxy or Duraform PA plus epoxy |
| Maximum Depth | Range of options available - up to 100m |
| Immersion sensor | Can be used to avoid wasted power when bird is submerged - please enquire |
Further Information
Base Station Options
We have three different models of base station for use with our range of nanoFix® GEO+RF tags: the fixed base station, which has a larger battery and solar panel. This unit is fully immersion proof and can be left in the field for extended periods of time in order to download data.
The mobile base stations come in white or black, and are ideal if you want to move around an area searching for your tagged animal. They are also immersion proof, but have a smaller battery and solar panel.
| Technical Specifications |  |  |  |
|---|---|---|---|
| Base Station Type | Fixed | Mobile | FCC Certified |
| Maximum operational battery life (without solar) | 28 days | 11 days | 28 days |
| Daily solar required to maintain battery level (Good/mixed sunlight) | 2 hours / 4 hours | 5 hours / 10 hours | 2 hours / 4 hours |
| Dimensions (excluding antenna, solar panels etc) | 121 x 89 x 81mm | 108 x 58 x 37mm | 128mm x 83mm x 69mm |
| Weight | 850g | 220g | 800g |
Deployments
Please click on the images below to see the specification for this product on a particular species.
Technology
Our Products
We have a wide variety of devices available, all of which have unique capabilities and characteristics. Please click on the variants below for detailed technical specifications.
