Tag Specification

Minimum Weight 8.0g
Minimum Dimensions 38 x 17 x 12mm, plus external whip antennas
Memory capacity ~60,000 Location attempts
Battery only capacity ~840 location, excluding GSM for 8.0g tag, more for larger tag options
Solar capacity ~24 per day in UK summer conditions excluding GSM for 8.0g tag, more for tags with larger solar panels
Programming interface PC programmer via USB
Waterproofing All immersion proof, depth proofing also available
Packaging type Epoxy or Duraform PA plus epoxy
Maximum Depth Range of options available - up to 100m
Immersion sensor Can be used to avoid wasted power when bird is submerged - please enquire
